Travel

X/Y/Z axis

mm

800/550/550

Spindle nose to worktable

mm

120-670

Spindle centre to column rail surface

mm

590

Rail type

Roller screw rails

worktable

size（ L*W)

mm

1000×550

Max load

kg

600

T-slot

No/mm

5-18*90

spindle

bore（taper/diameter）

mm

BT40φ140

speed

rpm

12000

Transmission type

Direct Drive

feed

X/Y/Z rapid displacement

m/min

36/36/36

Max cutting speed

mm/mi

n

10000

ATC(optional)

Tool exchange mode

Hanging on side

Tool bar spec

type

BT40

Tool capacity

tools

24T

Max diameter of tool（with neighbor tool）

mm

105

Max diameter of tool（without neighbor tool）

mm

200

Max length of tool

mm

350

Max weight of tool

kg

15

Max time of changing tools

sec

4

spindle

Spindle motor

kw

βis12-12000

3 axes servo motor power

kw

βis22-3000*2βis22b-3000

Pump motor of flushing ferri chips

m/h- m

4-60

accuracy

Positioning

mm

±0.005/300

Repeated positioning

mm

±0.003/300

Power required

Power consumption

KVA

25

Air pressure

Kg/cm

6-8

Machine

Size (L*W*H)

mm

2580*2175*2415

Weight

T

5.5
